3-Unit Gang Lawn Mower with Pneumatic Wheels | 84-Inch Reel Mower
Deliver a professional-quality finish across large turf areas with the Liberal 3-Unit Gang Lawn Mower with Pneumatic Rubber Wheels. Designed for golf courses, cricket grounds, football fields, polo grounds, municipal parks, universities, and large estates, this tractor-trailed reel mower combines an 84-inch (213 cm) total cutting width with three independently floating cutting units.
The pneumatic rubber wheels provide smoother transport and help reduce turf marking compared with conventional steel wheels, making this configuration particularly suitable for premium sports turf. The ground-driven reel system operates through the mower’s wheels, so no tractor PTO is required for reel drive.
Built for use with 35–50 HP tractors, including commonly used Millat and Al-Ghazi models, the Liberal 3-Unit Gang Mower provides a practical solution for high-area turf maintenance where consistent reel cutting, productivity, and low mechanical complexity are important.
Key Features
- 84-inch / 213 cm total cutting width across three cutting units
- Three independently floating reel cutting units for improved ground contour following
- Pneumatic rubber turf-saver wheels for smoother transport and reduced surface marking
- Ground-driven reel operation through the mower wheels
- No PTO required for the reel cutting system
- 5- or 7-blade reel configurations available
- Adjustable cutting height from approximately 12 mm to 38 mm
- Heavy-duty mild-steel fabricated frame
- Heat-treated high-carbon steel reel blades
- Designed for tractors in the 35–50 HP range
- Industrial powder-coated finish
- Mechanical design requiring no dedicated engine or electronic control system
- Suitable for large-scale professional turf maintenance
Applications
The Liberal 3-Unit Gang Lawn Mower is designed for professional maintenance of large turf areas, including:
- Golf courses and fairways
- Cricket grounds and stadium outfields
- Football and sports fields
- Polo grounds
- University and school sports complexes
- Municipal parks and public grounds
- Large residential and institutional estates
- Military and government grounds
- Professional landscaping operations
- Sports turf contractors
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Liberal Lawn Mowers |
| Model | 3-Unit Gang Mower – Pneumatic |
| SKU | LLM-GM3-PW |
| Machine Type | Tractor-Trailed Gang Reel Mower |
| Number of Cutting Units | 3 |
| Total Cutting Width | 84 inches / 213 cm |
| Cutting Unit Width | Approximately 28 inches per unit |
| Cutting Height | 12–38 mm Adjustable |
| Reel Blades | 5 or 7 Blade Reels Available |
| Blade Material | Heat-Treated High-Carbon Steel |
| Wheel Type | Pneumatic Rubber |
| Wheel Size | 16 inches |
| Drive System | Ground Drive via Wheels |
| PTO Requirement | Not Required for Reel Drive |
| Recommended Tractor | 35–50 HP |
| Recommended Tractor Models | Millat MF-240, MF-260, MF-375 and compatible Al-Ghazi tractors |
| Approximate Weight | 580 kg |
| Dimensions | 96 × 88 × 40 inches (L × W × H), approximately |
| Frame Material | Heavy-Duty Mild Steel |
| Finish | Industrial Powder Coated |
| Country of Origin | Pakistan |
| Availability | Made to Order |
| Warranty | 1 Year on Liberal Manufactured Parts |
Pneumatic Rubber Wheels for Premium Turf
The pneumatic wheel configuration is designed for operations where protecting the turf surface is a priority. Compared with rigid steel wheels, pneumatic tyres provide cushioning during transport and can help reduce visible wheel marking under suitable operating conditions.
This makes the pneumatic configuration particularly suitable for golf courses, cricket grounds, football fields, polo grounds, and other professionally maintained turf areas.
Three Independent Floating Cutting Units
Each reel cutting unit is independently mounted to allow it to follow variations in ground level. This floating configuration helps maintain a more consistent cutting height when working across gently undulating turf.
The three-unit arrangement provides an 84-inch / 213 cm total cutting width, allowing large areas to be covered efficiently in a single pass.
Precision Reel Cutting System
The Liberal gang mower uses cylindrical reel cutting units designed to provide a clean, precise cut when correctly adjusted and maintained. 5-blade and 7-blade reel configurations are available depending on the intended turf application and cutting requirements.
Regular reel and bedknife adjustment, sharpening, and backlapping are important for maintaining optimum cutting performance.
Ground-Driven Operation – No PTO Required
The cutting reels are driven through the mower’s wheels as the machine is pulled across the turf. This ground-drive arrangement means the reel cutting system does not require tractor PTO power.
The mower is therefore mechanically straightforward, with no dedicated petrol or diesel engine required on the gang mower itself.
Tractor Compatibility
The 3-Unit Gang Lawn Mower is designed for use with tractors in the 35–50 HP range. Compatibility should be confirmed according to the tractor’s drawbar arrangement, tyre configuration, operating conditions, and manufacturer’s specifications.
The mower can be configured for commonly used tractors such as Millat MF-240, MF-260, MF-375 and compatible Al-Ghazi models.
Cutting Height Adjustment
The cutting height can be adjusted within an approximate range of 12 mm to 38 mm. Individual cutting units should be correctly adjusted and checked to ensure a consistent finished height across the complete cutting width.
Standard Package Includes
- 1 × 3-Unit Gang Mower Main Frame Assembly
- 3 × Independent Reel Cutting Units with Pneumatic Wheels
- 1 × Tractor Drawbar Hitch Assembly
- Height Adjustment Components
- Operation and Maintenance Manual
- Basic Tool Kit
Why Choose Liberal Lawn Mowers?
Liberal Lawn Mowers manufactures lawn-care and sports-ground machinery in Pakistan, supplying equipment for professional turf maintenance, sports facilities, landscaping contractors, institutions, and government organizations.
Our equipment is designed with practical consideration for local operating conditions, serviceability, fabrication requirements, and long-term maintenance. Technical assistance, spare parts, and after-sales support are available for Liberal-manufactured equipment.
Maintenance Requirements
- Daily: Check tyre pressure, inspect cutting units, grease applicable points, and remove grass or debris.
- Weekly: Check reel-to-bedknife adjustment, wheel bearings, fasteners, and general machine condition.
- Periodic: Backlap or sharpen reels and bedknives as required by operating hours and turf conditions.
- Seasonal: Carry out professional reel and bedknife grinding and replace worn components.
Always disconnect the mower from the tractor before carrying out maintenance, adjustment, cleaning, or repair work.
Frequently Asked Questions
What is the cutting width of the 3-unit gang mower?
The total cutting width is approximately 84 inches / 213 cm, using three cutting units of approximately 28 inches each.
What tractor is required?
A tractor in the 35–50 HP range is recommended. Compatibility should be confirmed based on the specific tractor and operating conditions.
Does the mower require PTO?
No. The reel cutting system is ground-driven through the mower wheels and does not require tractor PTO power for reel drive.
Why are pneumatic wheels used?
Pneumatic rubber wheels provide cushioning and smoother transport and are intended to reduce visible turf marking compared with rigid steel wheels under suitable operating conditions.
How many blades are available?
The gang mower is available with 5-blade or 7-blade reel configurations, depending on the required specification.
What is the cutting height?
The approximate adjustable cutting-height range is 12–38 mm.
Is the mower suitable for cricket grounds?
Yes. The 3-unit gang mower is suitable for maintaining large turf areas such as cricket outfields, sports grounds, golf courses, football fields, polo grounds, and municipal parks. Final suitability depends on turf type, required cutting height, and site conditions.
Is the machine available with steel wheels?
This product specification is the pneumatic-wheel configuration. Contact Liberal Lawn Mowers for information about other gang mower configurations.
Is the mower available for export?
Export arrangements can be discussed for GCC and other international markets. Contact Liberal Lawn Mowers for current export specifications, packing, freight, and delivery arrangements.
What is the warranty?
The machine carries a 1-year warranty on Liberal-manufactured parts, subject to the applicable warranty terms. Wear components and damage resulting from misuse or improper maintenance may be excluded.
Shipping & Delivery
The 3-Unit Gang Lawn Mower is available on a made-to-order basis. Production and delivery schedules depend on the required configuration, production workload, destination, quantity, and transportation arrangements.
For current production lead times and delivery arrangements, contact Liberal Lawn Mowers before placing an order.
